AL.SS-12t jumping-jet fountain nozzle

Like a laminar nozzle, the jumping jet nozzle forms water into a curved, crystal-clear rod. Its water-cutting technology and system produce attractive, interrupted water arches of various lengths and sizes, while coloured light within the transparent water rod creates a striking display. Installing these nozzles in groups, with a programmed control system that activates the jets at different intervals, enables beautiful group water dances throughout the day and night. This nozzle combines aluminium and 316 stainless steel to reduce cost and is suitable for indoor and outdoor use with or without suitable covering. Its stainless-steel base allows the water projection angle to be adjusted through 100 degrees, enabling vertical and horizontal projection. Special professional filters are needed to produce clear, crystalline water and eliminate turbulence. GSO nozzles therefore use professional cellulose filters, which increase water adhesion and cohesion. These filters are sensitive to suspended and solid matter such as algae and consequently require frequent cleaning. To improve quality and address this issue, suitable disc filters are recommended at the pump outlet or nozzle inlet. The nozzle control system uses the DMX/RDM protocol for programming and data transmission and is compatible with leading standard fountain software.



Specifications:

1. Outlet jet diameter as required: 10،12،14 mm
2. Material: aluminium and 316 stainless steel
3. Can be used individually or in groups
4. Operation independent of the water level
5. Can be installed inside the fountain basin
6. Water projection height from 0.5 to 5.5 metres
7. Jet angle adjustable from -5 to 95 degrees
8. Requires installation of a disc filter
9. Uses the standard DMX/RDM protocol
